▲ Purpose：
It is used for solution and aging heat treatment of aluminum alloy forgings.
▲ Product category：
1）Typical workpieces: Aluminum alloy castings such as automotive steering knuckles and automotive control arms;
2）Workpiece material: aluminum alloy castings, etc.
3）Loading form: Aluminum alloy castings are placed on the material rack.
4）Heating temperature: 540℃
5）Aging temperature: 150-200℃
6）Furnace temperature uniformity: ≤±5℃;
7）Heating method: Electric/natural gas heating;
8）Material conveying method: idler conveying;
9）Cooling system: External circulation + stirring circulation system;
10）Quenching method: Quenching by lifting roller conveyor and the entire workpiece in water.
11）Quenching time in water: ≤15 seconds;
